Yamaha 20hp Outboard | F20SMHB

Key Features

Max Maneuverability: A 45-degree steering angle in each direction means great maneuvering potential.

Easy Engine Flushing: A Freshwater Flush Device allows you to flush the engine without running it, for added convenience and extended engine life.

Portability and Storage: Incredible light weights, built-in resting pads and carry handles, an easy oil rentention system and an optional folding tiller handle, allow for easy carrying and on-side storage without oil leakage or cowling scuffs.

Motor Specifications

• • Engine Type: Yamaha F20SMHB Four Stroke
  • Horsepower: 20hp
  • Cylinders: 2 cyl
  • Shaft Length: 15″ Short
  • Steering: Tiller
  • Starter: Manual
  • Weight: 126 lbs
  • Alternator Output: 16 amp
  • Degree of Tilt: 62°- 63°
  • Degree of Trim: -3° through +16°
  • Full Throttle Range: 5000 – 6000 rpm
  • Displacement: 432cc
  • Fuel Induction System: Electronic Fuel Injection (EFI)
  • Warranty: Yamaha 3-Year Warranty

Standard Features

• • Aluminum Propeller
  • Fuel Line
  • Safety Lanyard
  • Owner’s Manual
